Mechatronics

Mechatronics by Dr. M. M. Bhoomkar, A. V. Chavan

Book Summary:

It gives us great pleasure to present the book 'Mechatronics' for the students of Third Year Degree Course in Mechanical Engineering of the Savitribai Phule Pune University. This book is strictly as per the New Revised Credit System Syllabus 2015 Pattern with effect from the Academic Year 2017-18.

As per New Revised Examination Scheme which has been implemented from this academic year, In-semester assessment carries 30 marks over first three units and End Semester Examination carries 70 marks over entire syllabus out of which first three units will carry 20 marks and units 4, 5, 6 will carry 50 marks. The theory course will have 4 credits.

The book is written such that all the basic concepts are explained in simplified manner. It is presented in a more conceptual manner rather than mathematical, as required by the new examination system. It is our objective to keep the presentation systematic, consistent, intensive and clear through explanatory notes and figures.

Audience of the Book :

This book Useful for Mechanical Engineering students.

Table of Contents:

1. Introduction To Mechatronics Sensors and Actuators

2. Block Diagram Representation

3. Data Acquisition

4. Programmable Logic Control

5. Frequency Domain Modelling and Analysis

6. Control System

LAB Manual (Experiment 1 to 10 with Oral Questions)

Model Question Papers
